Chapter 2 Name and Function of Parts
HRSH Series 2.1 Model Number of Product
2-1
Chapter 2 Name and Function of Parts
2.1 Model Number of Product
The product can be ordered with the model number configured as shown
below.
The product needs to be handled in different ways depending on the part
number. Refer to “1.4 Product Label" and check the part number of the
product.
HRSH
①Cooling capacity
②Cooling method
③Piping thread type
④Power supply
- - -
⑤Option
A Air-cooled refrigeration
None
Nill
Caster-adjuster foot
installed
A
*2：Manual fluid fill port that is different from
the automatic fluid-fill function.
This enables that circulating fluid can be
filled manually without removing the side panel.
(In case of without K option, circulating
fluid can be filled manually removing
the side panel.)
Nil
Rc
F G (Rc-G thread adapter set is included)
N
NPT (Rc-NPT thread adapter set is included)
A
20
100 10kW
250
200 20kW
25kW
*1：In case of power supply '40' and option S,
this is standard. (with a handle)
W Water-cooled refrigeration
150 15kW
Earth leakage breakerB
*1
Fluid fill port
K
*2
Earth leakage breaker
with a handle
B1
*1
Applicable to deionized
water piping
M
*3：Power supply '-20' only.
300
*6
30kW
*6：Air cooled only
High head pump
T
*4
*5： Unit : MPa/ ゜C (degree Celsius)
AC200V/200-230V(50/60Hz)
3phase
3-phase 380 to 415 VAC (50/60 Hz),
3-phase 460 to 480 VAC (60 Hz)
20
40
Fixed SI unit
W
*5
*4：W: Water-cooled only.
*6： HRSH300-A-20/40 Air cooled only.
CE / UL
S
*3
Fig. 2-1 Product model number
