ELECTRICITY SUPPLY
MODELS - comments
SUFFIX TO THE
MODEL NAME
ELECTRICITY SUPPLY
INTEGRAL PROTECTIVE
DEVICES
GW2145
-
230V ~ / 50Hz / 14A / 3300W
FUSES 10.3x38 16 A ON
POWER SUPPLY
[L1, N]
GW1160, GW4060, GW4190
Max voltage/power
Possible electrical versions:
The names of the models have different
suffixes to identify the power supply rating.
E.g. If the model does not have a suffix, e.g.
“GW4060” it will be three-phase, with
neutral, 400V between phases.
. Suffix “-3”: “GW4060-3”indicates three-
phase model, 230V between phases, no
neutral.
.Suffix “-1”: “GW4060-1” indicates single-
phase model.
. The numerical suffix “6” identifies the 60
Hz version of 230V models.
. Suffix “U”: North American models, 208V
convertible (* default connection)
standard
400V 3N~ / 50Hz / 12A / 7000W
FUSES 10.3x38 16 A ON
POWER SUPPLY
[L1, L2, L3]
-6
400V 3N~ / 60Hz / 12A / 7000W
FUSES 10.3x38 16 A ON
POWER SUPPLY
[L1, L2, L3]
-3
230V 3~ / 50Hz / 19A / 7000W
FUSES 10.3x38 20 A ON
POWER SUPPLY
[L1, L2, L3]
-36
230V 3~ / 60Hz / 19A / 7000W
FUSES 10.3x38 20 A ON
POWER SUPPLY
[L1, L2, L3]
-1
230V 1N~ / 50Hz / 12A / 2800W
FUSES 10.3x38 16 A ON
POWER SUPPLY
[L1, N]
-16
230V 1N~ / 60Hz / 12A / 2800W
FUSES 10.3x38 16 A ON
POWER SUPPLY
[L1, N]
-U
208V 3~ / 60Hz / 17A / 6000W *
FUSES 10.3x38 30 A ON
POWER SUPPLY
[L1, L2, L3]
208V ~ / 60Hz / 29A / 6000W
FUSES 10.3x38 30 A ON
POWER SUPPLY
[L1, L2]
OTHER DATA
DATA COMMUNICATION - PRINTER
CONNECTION
RS-232 PORT
MAX. NOISE LEVEL
50dB
AMBIENT CONDITIONS
USE
Indoor
ALTITUDE
Up to 1000m
AMBIENT TEMPERATURE
From 5°C to 40°C
MAX RELATIVE HUMIDITY
80% for temperatures up to 31°C with linear decrease to 50% at the
temperature of 40°C
INSTALLATION CATEGORY (OR SURGE CATEGORY or INSTALLATION
CATEGORY)
II
ELECTRICAL INSULATION CLASS (ref. IEC 61140)
I
DEGREE OF POLLUTION
2 (ref. 61010-1, point 3.6.6.2)
STANDARDS AND CLASSIFICATION
CONFORMITY - North American models
IEC61010-1(ed.2), IEC61010-2-040(ed.1), CAN/CSA C22.2 No. 61010-1-04 / UL 61010-1, 2nd
Edition
CONFORMITY - Other models
- European directive 2006/95/CE [Safety]: European Standard EN61010-1:2001, EN61010-2-
040:2005
- European directive 2004/108/CE [Emc] : European Standard EN61326:2006
- European directive 2011/65/CE (RoHS 2) : European Standard EN 50581 :2012
- Other: European Standard EN 61770:2009
