10 INSTALLATION
The device's characteristics and positioning and installation instructions are provided below.
10.1 TECHNICAL DATA
The documentation includes a description of the rated characteristics of the electrical connection, all the intake and
outlet connections and the ambient conditions for which the appliance was designed.
For “non electric” intakes, the pressure and flow ranges are provided (ref. point 5.4.2 IEC61010-2-040:2015).
WATER SUPPLY REQUIRED
Type of water required
1 - Mains (required)
2 - Demineralised
(recommended)
Pressure
200 kPa – 500 kPa (2 bar – 5 bar)
Type of threaded connection
3 / 4 ”
Required flow [min - max]
2 - 12 litres / min
Mains water hardness [max]
42 °f
(for models equipped with a steam condenser, the use of purified water with hardness
below 15°f is recommended).
Fe2+ / Fe3+ [max]
0.5 ppm
Cold water temperature [max]
35°C
Demineralised water conductivity [max]
30μS/cm
Limits depending on microbial
contamination
Minimum microbiological quality required: “potable water" (ref. limits
in accordance with Italian Legislative Decree 31/2001)
DIMENSIONS and WEIGHT
Series
Tethys D60, Tethys T60
Tethys T45
Standard External [Height x Width x
Depth]
850 x 600 x 600
850 x 450 x 620
Standard External - aquastop accessory
[Height x Width x Depth] - overall height is
increased by +7mm
857 x 600 x 600
-
Net weight
72 kg
56 kg
Weight of appliance + packaging
90 kg
66 kg
MATERIALS
Washing chamber
AISI 316L
External surface
AISI 304
