Smeg WD2145 - Page 17

User Manual
WD2145-WD1160-WD4060-WD4190
Page 17 - 85
fig. 6 – Opening the side cabinet hatch WD4190.
fig. 7 – Once the side cabinet hatch is open, the user has access to the device’s master switch (and the printer, if installed).
fig. 8 – The RS-232 data port and the data output switch (which directs data either to the transmission port or to the printer) are located above the
master switch panel.
RS-232
DATA PORT
DATA
OUTPUT
SWITCH
