5 DESCRIPTION OF CONTROLS AND PROGRAMS
5.1 CONTROLS
All the device’s control and monitoring devices are placed together on the front panel.
WD4060, WD4190 CONTROL PANEL
WD2145, WD1160 CONTROL PANEL
fig. 9 – Control panel. The display and indicator LEDs are in the middle and the control buttons at the sides and bottom.
CONTROL PANEL SYMBOLS
SYMBOL
MEANING
SYMBOL
MEANING
On/Off
Functions
Drying Decrease
(only on WD4060, WD4190 series)
Drying Increase
(only on WD4060, WD4190 series)
Start / Stop
Door opening
Selection
Selection
The diagrams below only us the layout relating to WD4060 models. The same remarks and
procedures also apply for models WD2145, WD1160 and WD4190, unless otherwise specified.
