WD2145-WD1160-WD4060-WD4190
On the WD4190 series, the detergent intake connections “P1” and “P2” are inside the side
cabinet and are accessed by opening the hatch. The connections are marked for identification
with P1 (detergent) and P2 (acid neutraliser).
WD4190 - front view, side cabinet open.
10.3.2 INSTALLATION ON STAND– APPLIANCE STAND
If the device is installed on a stand (e.g. product “B6040L” for WD1160, WD4060, “B9040L” for WD4190) with having
height (base height) "HB", all the measurements of height above the supporting surface provided in this document
must be increased by the said height “HB”.
