1 INTRODUCTION
WD2145, WD1160, WD4060, WD4190 - instrument washers for use in hospitals, class IIb medical devices (in
accordance with the classification criteria established by Directive 93/42 and subsequent additions and amendments,
extended and amended by EC Directive 2007/47).
WD1160, WD4060, WD4190 family products comply with all the prerequisites of the relevant safety regulations and
the standards in force for electrical equipment.
This manual describes four products:
• WD2145: instrument washer 45 cm wide, without drying system
• WD1160 Series, instrument washers, 60cm, without drying system.
• WD4060 Series: instrument washers, 60cm, equipped with forced air drying system.
• WD4190 Series: instrument washers, 90cm, equipped with forced air drying system and side
cabinet to take detergent cans.
The diagrams and images contained in this document refer to the WD4060 series. For the WD2145,
WD1160, WD4190 series the same considerations and procedures apply, unless otherwise specified.
The table below summarises the product’s main characteristics. (For a full list of models and their configurations refer
to the “LIST OF MODELS
” point below).
Basic WD
CONTROL
ELECTRONIC with MICROPROCESSOR
(with Time and Date functions)
DOOR OPENING
Automatic
DETERGENT DISPENSING
Automatic, by means of
Peristaltic pumps (P1 and P2)
OPTIONAL DETERGENT DISPENSING
Optional peristaltic pump P3
CONTROL OF DETERGENT DISPENSING
Yes
DETERGENT JERRY CAN LEVEL CONTROL
Yes
TEMPERATURE CONTROL
Two probes, work and monitoring (TL1 and TCL)
STEAM CONDENSER
Yes
DRYING SYSTEM
Yes, forced air (WD4060, WD4190 series Only)
ABSOLUTE DRYING FILTER
Yes (WD4060, WD4190 series Only)
WATER INTAKE CONNECTIONS
Mains and Demineralised
PRESET PROGRAMS
Specific HOSPITAL, TOTAL OF 16 PROGRAMS, 6
“CUSTOM” (customisable using
TRACELOG software
1
. The software is not included in the
product’s basic outfit)
COMMUNICATION
RS-232 serial (For PC or Printer)
1
The TRACELOG software enables the user to communicate with “WD” and “GW” instrument and glassware washers.
Once the connection has been made, the user can:
- Keep a record of the disinfection cycles performed.
- Monitor the appliance’s status.
- Download new versions of the appliance’s software.
- Modify programs.
- Save the appliance parameter setup.
