Snap-On EEWB334A Operation Instructions

6
EEWB334A
3-1
3.1 Accessories
Refer to Figure 3-1.
The standard accessories are:
Quick-Release Hub Nut EAA0263G66A
Rubber protector ring EAC0058D15A
Pressure cup EAC0058D07A
Presure disk EAC0058D08A
Cone, 87-137 mm / 3.4”-5.4” EAM0003J69A
Cone, 96-114 mm / 3.8”-4.5” EAM0005D25A
Cone, 71-99 mm / 2.8”-3.9” EAM0005D24A
Cone, 40-76 mm / 1.6”-3.0” EAM0005D23A
Standard 40mm Stub Shaft EAM0021D90A
Fastening Rod EAM0005D34A
Pin EAM0006G01A
Flange EAC0060G02A
User Calibration weight EAM0005D40A
Weight pliers 8-04250A
