5.4.3.2. Storage duration period
Maximum storage up to a period of 12 months
(Recommendation: To be stored in dry, non corrosive and non saline atmospheric conditions)
5.4.3.3. Storage position
≤ 630 A: a maximum of 3 boxes may be stocked vertically
≥ 800 A: a maximum of 1 box may be stocked vertically
5.4.4. Volume and shipping weights by reference ATySt
Frame Size Rating
N° of
Poles
Reference
Number
Weight (kg)
Volume (cm)
inc Packing
Net Gross
B3
125 A
3
9543 3012
7,1 10,4 585x385x310
4
9543 4012
8,3 11,6 585x385x310
160 A
3
9543 3016
7,1 10,4 585x385x310
4
9543 4016
8,3 11,6 585x385x310
200 A
3
9543 3020
7,1 10,4 585x385x310
4
9543 4020
8,3 11,6 585x385x310
B4
250 A
3
9543 3025
8,0 11,3 585x385x310
4
9543 4025
8,8 12,1 585x385x310
315 A
3
9543 3031
8,1 11,4 585x385x310
4
9543 4031
9,2 12,5 585x385x310
400 A
3
9543 3040
8,1 11,4 585x385x310
4
9543 4040
9,2 12,5 585x385x310
B5
500 A
3
9543 3050
12,8 16,1 585x385x385
4
9543 4050
14,7 18,0 585x385x385
630 A
3
9543 3063
13,3 16,6 585x385x385
4
9543 4063
15,4 18,7 585x385x385
B6
800 A
3
9543 3080
29,0 45,0 730x800x600
4
9543 4080
33,3 49,3 730x800x600
1000 A
3
9543 3100
29,5 45,5 730x800x600
4
9543 4100
34,0 50,0 730x800x600
1250 A
3
9543 3120
30,0 46,0 730x800x600
4
9543 4120
34,7 50,7 730x800x600
B7 1600 A
3
9543 3160
34,2 50,2 730x800x600
4
9543 4160
40,5 56,5 730x800x600
B8
2000 A
3
9543 3200
51,8 67,8 730x800x600
4
9543 4200
62,7 78,7 730x800x600
2500 A
3
9543 3250
51,8 67,8 730x800x600
4
9543 4250
62,7 78,7 730x800x600
3200 A
3
9543 3320
62,1 78,1 730x800x600
4
9543 4320
76,4 92,4 730x800x600
