7.1.3. Power connection cross-section
 B3 B4 B5 B6 B7 B8
125 A 160 A 200 A 250 A 315 A 400 A 500 A 630 A 800 A 1000 A 1250 A 1600 A 2000 A 2500 A 3200 A
Minimum cable
section Cu (mm²)
35 35 50 95 120 185 2x95 2x120 2x185 - - - - - -
Recommended
cable section Cu
(mm²), Ith
- - - - - -
2x32
x5
2x40
x5
2x50
x5
2x63
x5
2x60
x7
2x100
x5
3x100
x5
2x100
x10
3x100
x10
Maximum cables
section Cu (mm
2
)
50 95 120 150 240 240 2x185 2x300 2x300 4x185 4x185 6x185 - - -
Maximum bars
width Cu (mm)
25 25 25 32 32 32 50 50 63 63 63 100 100 100 100
Note for all ratings: Take into account the connection cable lengths and/or others environmental specic operating conditions.
