socomec ATyS t User Manual

28
EN
ATYSt - 541995C - SOCOMEC
6.1.2. Dimensions: Frame B6 & B7 (800 A to 1600 A)
3
6
= =
4
3
1
2
3
5
7
J mm
Fix. M
Y
Z1
T12,5 X T T
F
fix. 250
AA
B
AC
253,5
293
391,5
Y
48
164 250
89
U
51,5
169
200 280
V
166
138
165
9
12.5
8,5
15,75 15,75
5
5
16x11ø 9
ø15
15
15
28,5
28,5
8,5
50
60
90
33
30 30
45 45
25 25
3310
800 A - 1000 A 1250 A 1600 A - 3200 A
ø 12,5
1. Padlocking Facility: Locking bracket for up to 3 padlocks of dia. 4 – 8mm
2. Emergency manual operation: Maximum operating radius with an operating angle of 2x 90°
3. Connection and disconnection area
4. Terminal screens
5. Phase Barriers
6. Emergency removable handle
7. Flush mounting cutout dimensions for front door
800 A 1000 A 1250 A 1600 A
3P 4P 3P 4P 3P 4P 3P 4P
AA
321 321 321 321 330 330 288 288
AC
461 461 461 461 461 461 531 531
B
370 370 370 370 370 370 380 380
F
504 584 504 584 504 584 596 716
J
307 387 307 387 307 387 399 519
M
255 335 255 335 255 335 347 467
T
80 80 80 80 80 80 120 120
U
50 50 50 50 60 60 90 90
V
60.5 60.5 60.5 60.5 65 65 44 44
X
47.5 47.5 47.5 47.5 47.5 47.5 53 53
Y
7 7 7 7 7 7 8 8
Z1
66.5 66.5 66.5 66.5 66.5 66.5 67.5 67.5
CAUTION
To consider the space required for manual operation and wiring (when using the ATySg
emergency handle: note 2).
