• Pin 415: Input I3, Manual Retransfer
RTC – Manual retransfer inhibits the “with priority” conguration order when closed with 417. This allows to control the
retransfer back to the priority supply at a specic (less consequent) moment. This input is useful when using the “with
priority” function.
• Pin416: Input I4, Inhibition
This input contact inhibits the ATS automation when closed with 417 without activating any other operating modes.
With inhibition active, the ATySt may be operated in manual mode (with the direct handle) or in remote control mode
with contacts 312 – 317 closed.
• Pin417:Common
Common supply for xed inputs 1 – 4 on terminals 413 to 416.
8.2.3.2. Technical data
MOTORISATION MODULE ATS CONTROL MODULE
Input Qty 5 6
Direct Current Iin 0.35 to 0.5mA 1 to 2.5mA
Line resistance 1kΩ 1kΩ
Line length 100m (Min. wire 1.5mm² #16AWG) 100m (Min. wire 1.5mm² #16AWG)
Pulse duration 60ms 60ms
Power per Input 0.06VA 0.03VA
Surge protectionVin_sg 4.8kV (1.2/50µs surge) 2.4kV (1.2/50µs surge)
ESD withstand voltage (Contact/air) 2/4kV 2/4kV
Insulation (Common mode) 4.8kVAC
(Between I/P and all common parts)
4.8kVAC
(Between I/P and all common parts)
Terminal connector 1.5mm² minimum / 2.5mm² max 1.5mm² minimum / 2.5mm² max
