ATYSt - 541995C - SOCOMEC
800 to 3200 A
ThermalcurrentI
th
at 40°C 800 A 1000 A 1250 A 1600 A 2000 A 2500 A 3200 A
Framesize B6 B6 B6 B7 B8 B8 B8
Rated insulation voltage U
i
(V) (power circuit) 1000 1000 1000 1000 1000 1000 1000
Rated impulse withstand voltage U
imp
(kV) (power circuit) 12 12 12 12 12 12 12
Rated insulation voltage U
i
(V) (control circuit) 300 300 300 300 300 300 300
Rated impulse withstand voltage U
imp
(kV) (control circuit) 4 4 4 4 4 4 4
Rated operational currents I
e
(A) according to IEC 60947-3
Ratedvoltage Utilisationcategory A/B
(1)
A/B
(1)
A/B
(1)
A/B
(1)
A/B
(1)
A/B
(1)
A/B
(1)
415 VAC AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2500 -/3200
415 VAC AC-22 A / AC-22 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2500 -/3200
415 VAC AC-23 A / AC-23 B 800/800 1000/1000 1250/1250 1250/1250 -/1600 -/1600 -/1600
500 VAC AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2000 -/2000
500 VAC AC-22 A / AC-22 B 630/630 800/800 1000/1000 1600/1600
500 VAC AC-23 A / AC-23 B 630/630 630/630 800/800 1000/1000
690 VAC
(3)
AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2000 -/2000
690 VAC
(3)
AC-22 A / AC-22 B 630/630 800/800 1000/1000 1000/1000
690 VAC
(3)
AC-23 A / AC-23 B 630/630 630/630 800/800 800/800
220 VDC DC-21 A / DC-21 B 800/800 1000/1000 1250/1250 1250/1250
220 VDC DC-22 A / DC-22 B 800/800 1000/1000 1250/1250 1250/1250
220 VDC DC-23 A / DC-23 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(2)
DC-21 A / DC-21 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(2)
DC-22 A / DC-22 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(2)
DC-23 A / DC-23 B 800/800 1000/1000 1250/1250 1250/1250
Rated operational currents I
e
(A) according to IEC 60947-6-1
Ratedvoltage Utilisationcategory
415 VAC AC-31 B 800 1000 1250 1600 2000 2500 3200
415 VAC AC-32 B 800 1000 1250 1250 2000 2000 2000
415 VAC AC-33 B 800 1000 1000 1000 1250 1250 1250
Current rated as conditional short-circuit with fuse gG DIN, according to IEC 60947-3
Prospective fuse protected short-circuit withstand at 415 VAC(kA rms) 50 50 100 100
Prospective fuse protected short-circuit withstand at 690 VAC(kA rms) 50 50 50
Associated fuse rating (A) 800 1000 1250 2x800
Short-circuit withstand without protection as per IEC 60947-3
Rated short-time withstand current 0.3s I
cw
at 415 VAC (kA rms) 64 64 64 78 78 78 78
Rated short-time withstand current 1s I
cw
at 415 VAC (kA rms) 35 35 35 50 50 50 50
Rated peak withstand current at 415 VAC (kA peak) 55 55 80 110 120 120 120
Short-circuit withstand without protection as per IEC 60947-6-1
Rated short-time withstand current 30ms I
cw
at 415 VAC (kA rms)
Rated short-time withstand current 60ms I
cw
at 415 VAC (kA rms) 20 20 25 32 50 50 50
Connection
Minimum Cu cable cross-section as per IEC 60947-1 (mm²) 2 x 185
Recommended Cu busbar cross-section (mm²) 2 x 50 x 5 2 x 63 x 5 2 x 60 x7 2 x 100 x 5 3 x 100 x 5 2 x 100 x 10 3 x 100 x 10
Maximum Cu cable cross-section (mm²) 4 x 185 4 x 185 4 x 185 6 x 185
Maximum Cu busbar width (mm) 63 63 63 100 100 100 100
Min./max. tightening torque (Nm) 9/13 9/13 20/26 40/45 40/45 40/45 40/45
Switching time (rated voltage, after receiving command)
Transfer time I-II or II-I (s) 2.8 2.8 2.8 2.9 2.8 2.8 2.8
I-0 or II-0 (s) 1.4 1.4 1.4 1.4 1.8 1.8 1.8
Contact transfer time ("black-out" I-II) minimum (s) 1.4 1.4 1.4 1.5 1 1 1
Power supply
Min./max. power (VAC) 166/332 166/332 166/332 166/332 166/332 166/332 166/332
Control supply power demand
Demand/rated power (VA) - ATyS r, ATyS d 460/184 460/184 460/184 460/230 812/322 812/322 812/322
Demand/rated power (VA) - ATyS t, g , p 482/206 482/206 482/206 482/252 834/344 834/344 834/344
Mechanical specifications
Durability (number of operating cycles) 4,000 4,000 4,000 3,000 3,000 3,000 3,000
Weight ATyS r 3 P / 4 P (kg) 27.9/ 32.2 28.4/ 32.9 28.9/ 33.6 33.1/ 39.4 50.7/ 61.6 50.7/ 61.6 61.0/ 75.3
Weight ATyS d 3 P / 4 P (kg) 28.5/ 32.8 29.0/ 33.5 29.5/ 34.2 33.7/ 40.0 51.3/ 62.2 51.3/ 62.2 61.6/ 75.9
Weight ATyS t, g, p 3 P / 4 P (kg) 29.0/ 33.3 29.5/ 34.0 30.0/ 34.7 34.2/ 40.5 51.8/ 62.7 51.8/ 62.7 62.1/ 76.4
(1) Category with index A = frequent operation - Category with index B = infrequent operation.
(2) 3-pole device with 2 pole in series for the “+” an 1 pole for the “-”.
4-pole device with 2 poles in series by polarity.
(3) Interphase barriers must be installed on the products.
(4) Values given at 690 VAC.
