socomec DIRIS B-10L User Manual

10
EN
DIRIS B-10L - 551174A - SOCOMEC
4. PRESENTATION
4.1. DIRIS B-10L presentation
The DIRIS B-10L is a compact PMD* which communicates measurement data over a LoRaWAN wireless communication
network. The wireless communication link is particularly useful for monitoring loads located in isolated, remote areas, without
the need to set up a cabled communication link.
The DIRIS B-10L is designed for monitoring energy, power and various other parameters and can be used to jointly analyse
single-phase and three-phase loads. Optional modules can be added to manage multi-utility energy meters (water, gas, etc.)
and additional inputs/outputs (Digital, temperature, etc.)
Current sensors are connected via an RJ12 cable which allows a quick and easy installation. The type of current sensor
and their current rating is automatically detected by the DIRIS B-10L which signicantly reduces the risk of errors during
installation.
A global class 0.5 accuracy is guaranteed for the DIRIS B-10L and associated current sensors.
The DIRIS B-10L is congured from the Easy Cong System software. The measurements can be accessed via the
LoRaWAN network or via Modbus TCP thanks to a dedicated LoRaWAN to Ethernet gateway.
* PMD: Power Monitoring Device in accordance with IEC 61557-12.
4.1.1. Range
PMD DIRIS B-10L
Communication LoRaWAN
Ref. 48290900
Accessories
Remote antenna
+ 3m extension cable
Sealing kit.
To secure terminals U/ I
USB cable for configuration
Ref. 48540126 Ref. 48290049 Ref. 48290050
