5.4.3. Plate mounting
TE-18
1x
diameter0.17 /
4.2 M4max
1Nm
0.81
20.5
1.05
26.8
1
1
2
2
2
2
3
3
TE-25 - > TE-55
4x
diameter0.20
/ 5.2 M5max
1Nm
