DIRIS B-10L - 551174A - SOCOMEC
2.2. Risk of damaging the device
Caution: risk of electric shock Ref. ISO 7000-0434B (2004-01)
Caution Refer to the accompanying documentation each time this
symbol is shown
Ref. ISO 7000-0434B (2004-01)
To ensure that the device operates correctly, make sure that:
The device is correctly installed.
The auxiliary power supply voltage indicated on the device is observed: 110V - 230 VAC (± 15%).
The network frequency indicated on the device is observed: 50 or 60 Hz.
A maximum voltage at the voltage input terminals of 520 VAC phase/phase or 300 VAC phase/neutral is observed.
Always connect the TE, TR/iTR or TF current sensors using the recommended connection cables and observing the
maximum prescribed currents.
Failure to respect these precautions could cause damage to the device.
2.3. Liability
Assembly, connection and use must be carried out in accordance with the installation standards currently in force.
The device must be installed in accordance with the rules given in this manual.
Failure to observe the rules for installing this device may compromise the device’s intrinsic protection.
The device must be positioned within an installation which complies with the standards currently in force.
Any cables which need to be replaced may only be replaced with cables with the correct ratings.
