ENGLISH
IOMMASIPXX09-GB 04
37
10-40 kVA
MASTERYS IP+
Once the code is obtained, enter it by pressing ENTER to activate the entry (two asterisks will appear). Select the
rst character with the UP
and DOWN keys and con rm with ENTER to accept the character. Then move
on to the next character. Pressing the ENTER key after selecting the fourth character activates code.
SEE INSTALLATION MANUAL
FOR PROCEDURE
CODE = - - - - **
An error message is displayed if the code is incorrect.
Check that the code displayed corresponds to the one provided by the Support Centre and repeat the procedure.
8.5.2 “Present con gurations” menu.
This is used to change the con guration parameters.
Press ENTER. Access is via the password MAST which is keyed in by using the UP
and DOWN keys and
ENTER to go on to the next letter.
Note.
Column A shows whether the parameter is visible in the PARAMETERS “CONFIGURATIONS” menu.
PRESENT CONFIGURATIONS menu
A Parameter Description Allowed values
LANGUAGE SELECTION Selects the required language DE-EN-ES-FR-IT, others on request
• NUMBER OF MODULES Only appears in case of parallel systems. 1-6
Indicates the number of UPSs in the system.
• REDUNDANCY LEVEL Only appears in case of parallel systems. FROM 0 TO THE NUMBER
Indicates the number of redundant UPSs. OF MODULES LESS ONE
• OUTPUT VOLTAGE Sets the required output voltage value. 208/220/230/240
• OUTPUT FREQUENCY Sets the required output frequency value. 50/60
• CONVERTER Sets whether the UPS has to operate as a frequency YES/NO
converter.
WARNING!
Set only on UPS with mains power (MAINS) and auxiliary mains (AUX MAINS) separated
and with the auxiliary mains (AUX MAINS) disconnected!
Do not set on UPS with common mains lines as it could damage the load!
• AUTO ON Sets whether the UPS has to restart automatically after YES/NO
shutdown due to minimum battery level.
BATTERY AVAILABLE Indicates whether the batteries are present YES/NO
BATTERY TEMP. PROBE Indicates if the battery sensor is present ENABLE/DISABLE
•
BATTERY TYPE Selects the type of batteries used SEALED, OPEN VENT, NI-CD
•
BATTERY RECHARGE Selects the type of recharge required AUTO, MAINTENANCE,
2 LEVELS, INTERMITTENT
• BATTERY CAPACITY Sets the battery capacity in Ah. 6,50 ÷ 1.000 (x number of UPS)
• BATTERY ELEMENTS Indicates the number of elements in series
114÷132
in a branch.
MENU
8
