socomec MASTERYS IP Plus User Manual

ITALIANOENGLISH
60 IOMMASIPXX09-GB 04
10-40 kVA
MASTERYS IP+
PARALLEL CONFIGURATION
RIGHT UPS
L13 L23 N3L33
IN
TRANSFORMER
EXT. BATTERY
+B2 -B2 -B1 +B1
OUTPUT
MAINS
SUPPLY
OUT
TRANSFORMER
L11 L21 L31 N1
N1
L14 L24 L34 N4 L12 L22 L32 N2L1
L1
L2 L3 N
AUXILIARY
MAINS
MAINS
SUPPLY
L11 L21 L31L2 L3 N
AUXILIARY
MAINS
EXT. BATTERY
+B2 -B2 -B1 +B1
TA1 TA2 TA5TA4
TA1 TA2 TA5TA4
OUTPUT
L14 L24 L34 N4
AUXILIARY
MAINS
AUXILIARY
MAINS
TO
LOAD
LEFT UPS
MAINS
MAINS
cable section: ø 1.5 - 2.5 mm
2
Cables provided
3/3
PARALLEL 1+1 REDUNDANT CONFIGURATION CONNECTIONS.
Output transformer (standard con guration).
WARNING!
Before connecting TA4 and TA5 remove the bridge cable from TA4-TA5 on both UPSs
Cables
Cables
provided
provided
