V/
Key Press
Resulting
Display
SEGMENTS 00002
( )
-=i
SEGMENTS 00008
(
8)
Set the
other sweep parameters to the following:
•
(OFF MODE} to [standby]
•
{DELAY}
to
1 second
•
{VI
RMP}to-l volt
•
{T1 RMP} to 10
seconds
•
{V2RMP} to
1
volt
• {T2
RMP} to 15 seconds
•
{V3 RMP}
to 1
volt
• (T3 RMP} to 10 seconds
•
{V4RMP} to
-1
volt
•
{T4 RMP} to 15 seconds
The ramp rate can be calculated by:
(V2-V
1
)/Tl in V/seconds.
For
further details of the sweep parameters
refer
to
Chapter
3,
section 8.
DATA
OUTPUT
Now press the "DATA OUTPUT" key. The
following will be displayed:
Key Press
Resulting Display
FILE/
STATUS
{
RS-423
(
[off
j
1
I 3.188nA
V
...
••
Set the following parameters:
•
{PARI} to [I]
•
{PAR2} to [POL]
Leave the other parameters as
the default settings; refer to Chapter
3,
section 1
5
further details of parameters and the defaults.
DVM
Now press
the "DVM" key again, and change the
{TRIGGER} from [Recycle] to
[Sync.]
CSB/SI1287 User Guide/issue AF
2.11
