Solax TRIPLE POWER TP-LD53 User Manual

27
6 Mechanical Installation
6.1 Installation Options
There are two installation options (floor mounting and wall mounting) are available, with
details as follows:
Option A: Floor Mounting
500 mm
Option B: Wall Mounting
500 mm
Figure 6-1 Installation options
NOTICE!
• The Figure 6-1 takes two battery modules as an example.
• Both the floor mounting and the wall mounting may withstand up to sixteen battery
modules.
