7
Product Overview
2.2.1 Label
Some kinds of labels, such as a performance label, a manufacturer label, etc., should be
pasted on the battery module. The above-mentioned labels are located on the right side of
the battery module. For example, the performance label consists of the following parts:
Serial number
Certification
marks
Parameter
information
Lithium ion Rechargeable Battery Module
Battery Type: LiFePO4
Model No.: TP-LD53
(IFpP/53/149/113/[(16S)]M/-20+50/90)
Nominal Capacity: 104 Ah
Nominal Energy: 5.32 kWh
Nominal Voltage: 51.2 Vdc
Max. Charge/Discharge Current: 100 A
Ingress Protection: IP65
Charge Temperature: 0~+53°C
Discharge Temperature: -20°C~+53°C
Storage Temperature: 30~+50°C (6 months)
-20~+30°C (12 months)
CM:
□
A
□
C
□
E
□
G
Certified to UN38.3 / IEC 62619 / CE
DANGER / HIGH VOLTAGE INSIDE
SN:
SolaX Power Network Technology (Zhejiang) Co., Ltd.
ADD.: No. 288, Shizhu Road, Tonglu Economic Development Zone,
Tonglu City, Zhejiang Province, 310000 P.R. CHINA
TEL: +86 571 5626 0011 E-mail: info@solaxpower.com
www.solaxpower.com MADE IN CHINA
320201116501
Figure 2-3 Label
Regarding the SN, 32-base nomenclature is adopted to identify the type, specific features,
manufacture date, order serial number, and factory serial number of a battery module.
32-base Nomenclature
2 0H 38 0 E 0 1F 7H 01
Factory Serial Number
Order Serial Number
Date of Manufacture
Year of Manufacture
Battery Cell Information
Hardware Version
Rated Capacity: 104 Ah
Model Type: TP-LD53
Rechargeable Battery
1
0-2023, 1-2024, 2-2025 …… A-2033, B-2034 ……
2
The two digits represent the week of when the battery module was produced. There
are totalling 52 weeks in a year, and the first week is represented by the number
00, and the second week is represented by the number 01. Do the rest in the same
manner in accordance with the 32-base coding rule.
