28
Mechanical Installation
6.2 Installation Procedure
WARNING!
• Only the qualified personnel can perform the mechanical installation following the
local standards and requirements.
• Check the existing power cables or other piping in the wall to prevent electric shock
or other damage.
• The bi-directional energy storage inverter connected with the battery module must
be an isolated inverter.
CAUTION!
• Always be aware of the weight of the battery. Personal injuries may result if the
battery is lifted improperly or dropped while being transported or mounted.
• Be sure you have all the proper protective clothing, safety tools, and equipment on
hand before stating the installation.
• Keep the work area clean and well lit. Cluttered or dark areas invite accidents.
NOTICE!
• Both the floor and wall mounting may withstand up to sixteen battery modules.
Table 6-1 Number of battery module
Floor mounting Wall mounting
Max. number of battery modules 16 16
• Either the floor or wall mounting, the bearing capacity of the grounding or the wall,
which enables it to bear the loads from the whole battery system, must be over 200
kg.
Table 6-2 Bearing capacity
Floor mounting Wall mounting
Bearing capacity of the supporting surface of a battery module ≥ 200 kg ≥ 200 kg
• Either the floor or wall mounting, the distance from the battery module to the wall,
the neighbouring battery module, or the grounding shall be provided as below.
Table 6-3 Distance requirement
Floor mounting Wall mounting
Distance from the edge of the battery module to the wall 200 mm ~ 300 mm 200 mm ~ 300 mm
Distance from the back of the battery module to the wall 55 mm 55 mm
Distance from the edge of the battery module to the edge of the
neighbouring battery module
400 mm ~ 600 mm 400 mm ~ 600 mm
Distance from the bottom of the battery module to the ground / 300 mm ~ 350 mm
To Next Page
