5
2 Product Overview
WARNING!
• The bi-directional energy storage inverter connected with the battery module must
be an isolated inverter.
2.1 System Description
The battery system consists of one or more rechargeable batteries. A battery module is a
type of electrical battery which can charge or discharge loads.
There are two installation options, such as floor mounting and wall mounting, that a user
can select from.
2.2 Appearance, Weight and Dimensions
Appearance
Electrical
connection
area
Indicator panel
Electrical
connection
area
Labels
Handle
Figure 2-1 Appearance
