Mechanical Installation
Step 2: Locate the L-shaped wall bracket against the wall.
Concrete wall or
solid brick wall
with a minimum
thickness of 100
mm
Front view Left side view
55 mm
Figure 6-3 Locating the battery module against the wall
NOTICE!
• At least two persons are required to lift the battery module.
Step 3: Draw a circle along the inner ring, with one on each side. Then gently move the
battery module aside.
Figure 6-4 Drawing circles
To Next Page
