SonicWALL SonicWave 224w - Sonicwave 200 Series Specifications

SonicWall SonicWave Deployment Guide
Product Specifications
25
SonicWave 200 Series Specifications
Hardware Specifications
Standards and Compliance
Environmental
Specification SonicWave 231c SonicWave 224w SonicWave 231o
Location Ceiling Wall Outdoor
Radio 2x2 802.11ac Wave 2
Dedicated 3rd scanning radio Yes No Yes
USB 2.0 Yes No No
Bluetooth Low Energy (BLE) radio Yes Yes Yes
AntennaType Internal Internal Omni-Antenna
Dimensions 118mmx214mmx34mm 122mmx188mmx18mm 190mmx120mmx42mm
Shipping dimension 150mmx240mmx73mm 150mmx240mmx73mm 265mmx450mmx78mm
Unit weight 0.4 kg 0.4 kg 0.7 kg
WEEE weight 0.7 kg 0.7 kg 2.0 kg
Shipping weight 0.7 kg 0.7 kg 2.0 kg
PoE
802.3af PoE (standard) 802.3at PoE (standard, sold
separately)
802.3af POE
DC 12V adapter (optional) DC 12V adapter (optional) (PoE sold separately)
Maximum power consumption (W) 12W 12W 12W
Status Indicator 4 5 4
Wired network ports 1 x 10/100/1000 auto-sensing
RJ-45
3 x 10/100/1000, 2x
10/100/1000, PoE Pass
through, 1 LAN PoE Out
1 x 10/100/1000 auto-sensing
RJ-45
Accessories included Ceiling/wall mounting kit NEMA 4x Mounting kit and
external antennas
Virtual access points Up to 8 per access point.
Chassis Rectangle
Standard SonicWave 231c SonicWave 224w SonicWave 231o
IEEE Standard 802.11a/b/g/n/ac
Compliance IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11e, IEEE 802.11i,
IEEE 802.3at, IEEE 802.3bz, WPA, TKIP, AES, IEEE 802.11r, IEEE 802.11k, IEEE 802.11v, IEEE 802.11w
Plenum rated Yes No No
Regulatory FCC, IC/ISED, CE, RCM, NCC, TELEC, KCC
Safety UL, cUL, TUV-GS, CB, UL Mexico CoC
MIMO MU-MIMO
Max/Recommended connected
clients per radio
128/30
Specification SonicWave 231c SonicWave 224w SonicWave 231o
Temperature Range 0
o
to 40
o
C0
o
to 40
o
C-30
o
to 60
o
C
Humidity 0% - 95%, typical 0% - 95%, typical 5% - 90%, typical
