SonicWall SonicWave Deployment Guide
Power Requirements
6
48
Power Requirements
SonicWave PoE Standards
1 When this product's power is provided by the Ethernet cable plugged in to the “LAN/POE” port, this is
called “Power over Ethernet” or “PoE”. The PoE source should only be UL listed marked “Class 2” or “LPS”
with an output rated 48 VDC, minimum 0.3 A, Tma: minimum 40 degrees C
.
2 Sold separately, available from SonicWall. When powering via external power adapter via barrel jack, use
only UL listed power supply marked “Class 2” or “LPS” with output rated 12Vdc, min. 2.0A, Tma:
minimum 40 degrees C.
3 Sold separately, available from SonicWall.
4 One cable included with access point.
5 When this product's power is provided by the Ethernet cable plugged in to the “LAN1” port, this is called
“Power over Ethernet” or “PoE”. The PoE source should only be UL listed marked “Class 2” or “LPS” with
an output rated 48 VDC, minimum 0.6 A, Tma: minimum 40 degrees C.
6 To use PoE output on LAN4, the PoE power source must be used. PoE output can supply power to single
802.3af compliant device, (output is 48 VDC, maximum 0.3 A).
7 When powering via external power adapter via barrel jack, use only UL listed power supply marked
“Class 2” or “LPS” with output rated 12Vdc, min. 1.5A, Tma: minimum 40 degrees C.
8 When this product's power is provided by the Ethernet cable plugged in to the “LAN(PoE)” port, this is
called “Power over Ethernet” or “PoE”. The PoE source should only be UL listed marked “Class 2” or “LPS”
with an output rated 48 VDC, minimum 0.3 A, Tma: minimum 40 degrees C. Install PoE source in
environmental location as directed by PoE source manufacturer.
9 This product's power is provided by the Ethernet cable plugged into the “LAN1” port, this is called
“Power over Ethernet” or “PoE.” The PoE source should only be UL listed marked “Class 2” or “LPS” with
an output rated 48 VDC, minimum 0.6 A, Tma: minimum 40 degrees C.
10 If PoE output on LAN2 is used to power an 802.3af compliant device, the PoE source should only be UL
listed marked “Class 2” or “LPS,” with an output rated 48 VDC, minimum 1.26 A, Tma: minimum 40
degrees C. LAN2 PSE output is 48 VDC, maximum 0.3 A.
SonicWave
Model
PoE Input
Standard
PoE Output
Standard
Optional AC/DC
Power Supply
PoE Injector
Requirement
Cable
Requirements
231c 802.3af
1
N/A 12 VDC
2
Gigabit
3
CAT5e
4
224w 802.3at
5
802.3af
6
12 VDC
7
Gigabit
3
CAT5e
4
231o 802.3af
8
N/A N/A Gigabit
3
CAT5e
432e
802.3at
9
N/A N/A Gigabit
3
CAT5e
4
432i 802.3at
9
N/A N/A Gigabit
3
CAT5e
4
432o 802.3at
9
802.3af
10
N/A Multi-Gigabit
3
CAT5e
