SonicWALL SonicWave 224w - Sonicwave 400 Series Specifications

SonicWall SonicWave Deployment Guide
Product Specifications
27
SonicWave 400 Series Specifications
Hardware Specifications
Standards and Compliance
Enviromental
Specification SonicWave 432e SonicWave 432i SonicWave 432o
Location Indoor Indoor Outdoor
Dimensions 8.5(D) x 2.0(H) in
21.6(D) x 5.1(H) cm
8.5 (D) x 2.0 (H) in
21.6(D)x 5.1(H) cm
9.5(W)x9.3(D)x2.4(H)in
24.1(W)x23.6(D)x6.1(H) cm
Weight 1.1 kg / 2.5 lbs 1.0 kg / 2.2 lbs 2.2 kg /4.9 lbs
WEEE weight 1.4 kg / 3.1 lbs 1.2 kg / 2.6 lbs 4.1 kg / 9.1 lbs
Shipping weight 1.7 kg / 3.8 lbs 1.5kg / 3.3 lb 4.7 kg / 10.4 lbs
PoE 802.3at
Maximum power consumption (W) 18.8W 18.8W 21.2W
Status Indicators Six (6) LED (WLAN/Link)(LAN/Link) Power, Test
Wired network ports (1) 10/100/1000 auto-sensing RJ-45 for Ethernet (PoE): (1) 100/1000/2.5 GBE auto-sensing, RJ-45
for Ethernet; (1) RJ-45 console; USB 2.0 (except 432o)
Accessories included Wall / ceiling mount kit
Virtual access points Up to 8 per access point.
Chassis UL 1024 plenum rated
Standard SonicWave 432e SonicWave 432i SonicWave 432o
IEEE Standard 802.11a/b/g/n/ac Wave 2
Compliance IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11e, IEEE 802.11i,
IEEE802.3at, IEEE 802.3bz, WPA, TKIP, AES, IEEE 802.11r, IEEE 802.11k, IEEE 802.11v, IEEE 802.11w
Regulatory FCC/ICES Class B, CE, RCM/ACMA, VCCI Class B, TELEC, BSMI, NCC, MSIP, ANATEL, Customs Union
RoHs (Europe/China), WEEE
Safety UL, cUL, TUV/GS, CB, CE, BSMI, Mexico CoC, Custom Union
MIMO MU-MIMO 4x4 (4 streams)
Max/Recommended connected
clients per radio
128/30
Specification SonicWave 432e SonicWave 432i SonicWave 432o
Temperature Range 32
o
to 104
o
F, 0
o
to 40
o
C-40
o
to 140
o
F
-40
o
to 60
o
C
Humidity 10 — 95%, non-condensing
