SonicWall SonicWave Deployment Guide
Antenna Installation
39
For details regarding these alternately approved antennas (including important safety information) refer to the
respective antenna guides. Some antennas might not be offered for sale in all countries. Contact SonicWall for
purchasing information.
The SonicWave default antenna configuration only supports Omni/Dipole antennas as shipped from the factory.
When any other antenna or antenna pair is installed, the professional installer must correctly configure the
SonicWave for the new antennas before enabling the radios. Configuration instructions are included in this
guide and with each antenna.
P254-13 2.4/5G 12dBi/13dBi Panel 40°
* Default antennas provided with appliance.
† S124-12 and S154-15 must be used together.
‡ P124-10 and P154-12 must be used together.
CAUTION: To prevent damage to the SonicWave 432o, all RF output ports must be attached to an
approved antenna before the radios are enabled.
Antenna Mode Band (GHz) Antenna Gain (dBi) Antenna Type
Deflection
(Beamwidth)
