Bridging clock signals to a di󱐯erent connector
from an external device acting as the clock
master
Using the bridging function, it is possible to synchronize devices with dif-
ferent connectors. For example, a Pocket Operator acting as a clock mas-
ter can be used to synchronize a Volca or MIDI device connected to the
MEGA SYNTHESIS.
SYNC OUT
SYNC IN
Volcaseries
Volcaseries
SRCsetto
SYNC
oror
SRCsetto
MIDI
POseries
POseries
A.OUT set to ON
（→ P.85）
MIDIdevice
MIDIdevice
MIDI OUT
MIDI IN
Make only one device the clock master
OUTPUT
INPUT
TX.CK set to ON
（ → P.91）
SRCsetto
LN.IN
