Sonoscape E1 User Manual

4 Customizing Your System
46 Basic User Manual
Item Description
Measure Line Size Set the thickness of the measurement line.
Dist. Dash Line Disp. Enable or disable the display of a dash line between two
points when performing a distance measurement.
Vel. Cross Line Disp. Enable or disable the display of a reticle between two points
when performing a velocity measurement.
Ellip. Cross Line Disp. Enable or disable the display of dash lines for long and short
axes when performing an ellipse measurement.
Volume Flow Method Set the measurement method of volume flow.
Volume Flow with
Compensation TAmax
Set the coefficient of volume flow with compensation
TAmax.
Result Font Size Set the font size of the result box.
Result Font Color Set the font color of the result box.
BSA In accordance with the setting of this item, the system
calculates BSA value automatically after you enter the height
and weight of the patient on the Patient Information screen.
Keep Result Window
while unfreezing image
Enable or disable the display of the current result box when
unfreezing the image.
■ Result Position
Item Description
2D Set the position of the result box in 2D, M mode and Doppler
mode.
M+D

Sonoscape E1 Specifications

General

Type	Portable Ultrasound System
Display	15-inch LCD
Transducer Ports	2
Cine Loop	Yes
Imaging Modes	Color Doppler, Power Doppler
Applications	Obstetrics, Gynecology, Vascular, Musculoskeletal
Probe Connectors	2
Ports	VGA, USB, Ethernet
Supported Probes	Convex, Linear, Phased Array
