Sonoscape E1 User Manual

6 Acquiring Images
86 Basic User Manual
■ Sweep Speed
Sweep speed is used to set the sweep speed of the M trace. A faster speed is more suitable
to view the motion.
To adjust the sweep speed:
1. Press the function key to select Sweep Speed.
2. Rotate the function key to adjust the value.
■ Chroma
Chroma is used to colorize the gray scale image to enhance the discrimination capability.
To adjust the chroma:
1. Press the function key to select Chroma.
2. Rotate the function key to choose a color scheme.
■ Display Format
Display format is used to view the image better.
To adjust the display format:
1. Press the function key to select Display Form.
2. Rotate the function key to adjust the settings.
■ Persistence
Persistence is used to average consecutive frames to provide a smoother appearance with
less noise. Use lower persistence values for fast-moving organs or tissues and higher
persistence values for a smoother appearance.
To adjust the persistence:
1. Press the function key to select Persist.
2. Rotate the function key to adjust the settings.
■ Focus Area
By adjusting the focal area of ultrasound beam, increase the resolution of the special area
to focus and optimize the image.
To adjust Focus area:
1. Press the function key to select Focus Area.
2. Rotate the function key to adjust the settings.
You can also press the Focus switch to adjust the focus position.

Sonoscape E1 Specifications

General

Type	Portable Ultrasound System
Display	15-inch LCD
Transducer Ports	2
Cine Loop	Yes
Imaging Modes	Color Doppler, Power Doppler
Applications	Obstetrics, Gynecology, Vascular, Musculoskeletal
Probe Connectors	2
Ports	VGA, USB, Ethernet
Supported Probes	Convex, Linear, Phased Array
