Chapter 3: The Exam 29
Exam
2 Perform the first distance measurement.
See “To perform a measurement using the touch screen:” on page 27 or “To perform a
measurement using the directional controller:” on page 28.
The measurement is displayed in the upper left section of the screen and is updated as the
caliper moves.
3 Tap or select Next from the on-screen menu.
The second set of calipers is displayed on the screen.
4 Perform the second distance measurement.
The measurement is displayed in the upper left section of the screen and is updated as the
caliper moves.
If desired, press the Save key to save the image with the measurements displayed.
5 Press the Freeze key to return to live imaging and obtain the next image.
6 Press the Freeze key to return to the volume calculation menu.
The third set of calipers is displayed on the screen.
7 Perform the third distance measurement to complete the volume calculation.
The measurement and volume results are displayed in the upper left section of the screen.
If desired, press the Save key to save the image with the measurements displayed. If desired,
tap or select Done from the on-screen menu to remove the caliper.
8 Press the Freeze key to return to live imaging.
Image Storage
The iLook ultrasound system is equipped with internal memory that allows for up to 74 images to be
saved. After an image has been saved, it can be reviewed on the system. When no longer needed,
images can be deleted individually or all at once.
To save an image:
1 Press the Freeze key.
2 Press the Save key.
The system beeps once when the image has been saved. The image storage icon on the status
bar updates to reflect the total number of saved images.
To print an individual image:
1 Press the Freeze key.
2 Use the controls on the printer to print an image.
