24 Freezing, viewing frames, and zooming
Freezing, viewing frames, and
zooming
To freeze or unfreeze an image
Press Freeze.
Onafrozenimage,thecineiconandframe
numberappearinthelowerleft‐handcorner.
To move forward or backward in the cine
buffer
Onafrozenimage,turnthecineknob .
Thetotalnumberofframesappearsnextto
thecineicon.Thenumberchangestothe
currentframenumberasyoumoveforward
orbackward.
Youcanalsousethetouchpadtomoveinthe
cine.
To zoom in on an image
Youcanzoomin2DorColorimaging.Youcan
freezeorunfreezetheimageorchangethe
imagingmodeatanytimewhilezooming.
1 Press Zoom.AROIboxappears.
2 Usingthetouchpad,positiontheROIboxas
desired.
3 Press Zoom.
TheimageintheROIboxismagnified
by
100%,andthecontrolkeychangesto On.
4 (Optional)Iftheimageisfrozen,usethe
touchpadtopantheimageup,down,left,and
right.
Toexitzoom,press On.
Imaging modes and exams
available by transducer
Thetransduceryouusedetermineswhichexam
typesareavailable.Inaddition,theexamtype
youselectdetermineswhichimagingmodesare
available.
To change the exam type
Dooneofthefollowing:
•PressOptionsandselectExam.Thenclick
theexamtypeinthemenu.
•Onthepatientinformationform,clickthe
examtypeintheTypelistunderExam.
(See“Patientinformationform”on
page 27.)
WARNING:
To prevent misdiagnosis or harm to
the patient, understand your
system’s capabilities prior to use.
The diagnostic capability differs for
each transducer, exam type, and
imaging mode. In addition,
transducers have been developed
to specific criteria depending on
their physical application. These
criteria include biocompatability
requirements.
To avoid injury to the patient, use
only an Ophthalmic (Oph) when
performing imaging through the
eye. The FDA has established lower
acoustic energy limits for
ophthalmic use. The system will not
exceed these limits only if the Oph
exam type is selected.
