48 Calculations
To measure a Tissue Doppler Imaging (TDI)
waveform
1 EnsurethatTDIison.(See“PWDoppler
controls”onpage 22.)
2 OnafrozenDopplerspectraltrace,press
Calcs.
3 Fromthecalculationsmenu,selectTDI,and
thendothefollowingforeachmeasurement
youwanttotake:
a Fromthecalculationsmenu,selectthe
measurementname.
b Positionthecalipers.(See
“Workingwith
calipers”onpage 33.)
c Savethecalculation.(See“Tosavea
calculation”onpage 38.)
EMED calculations (S-FAST)
TheresultsfromEMEDcalculations
automaticallyappearintheEMEDworksheets.
See“EMEDworksheets(S‐FAST)”onpage 53.
EMEDcalculationsareavailableforallexamson
anycompatibletransducer.(See“Imagingmodes
andexamsavailablebytransducer”onpage 24.)
To perform an EMED calculation
1 Onafrozenimage,press Calcs.
2 Inthecalculationsmenu,selectthecalculation
name.
3 Performadistancemeasurement.(See“To
measuredistance”onpage 34.)
4 Savethemeasurement.See“Tosavea
calculation”onpage 38.
Gynecology (Gyn) calculations
Gynecology(Gyn)calculationsincludeUterus,
Ovary,Follicle,andVolume.Forinstructionsto
calculatevolume,see“Volumecalculations”on
page 51.
To measure uterus or ovary
1 Onafrozen2Dimage,press Calcs.
2 Fromthecalculationsmenu,selectGyn.
3 Dothefollowingforeachmeasurementyou
wanttotake:
a Selectthemeasurementnamefromthe
calculationsmenu.
b Positionthecalipers.(See“Workingwith
calipers”onpage 33.)
c Savethecalculation.(See“Tosavea
calculation”on
page 38.)
WARNING:
To avoid incorrect calculations,
verify that the patient information,
date, and time settings are accurate.
To avoid misdiagnosis or harming
the patient outcome, start a new
patient information form before
starting a new patient exam and
performing calculations. Starting a
new patient information form clears
the previous patient’s data. The
previous patient’s data will be
combined with the current patient
if the form is not first cleared. See
“To create a new patient
information form” on page 27.
Systems and Exam Types for Gynecology (Gyn)
Calculations
Exam Type S Series System
Gyn S-FAST
S-GYN
S-Women’s Health
