22 Imaging modes
To display the D -line
ThedefaultDopplerimagingmodeisPW
Doppler.Inthecardiacexam,youcanselectCW
Doppler.
1 PressModeandselectDoppler.
2 Doanyofthefollowingasneeded:
•Adjustcontrols.See“PWDoppler
controls”onpage 22.
•Usingtheto uchpad,positiontheD‐line
andgatewheredesired.Horizontal
movementsposition
theD‐line.Vertical
movementspositionthegate.
•(PWDoppler)Tocorrecttheangle
manually,dooneofthefollowing:
•Click,andthenusethetouchpad.
ClickingtogglesbetweentheD‐line
andanglecorrection.
• Freezetheimage,andthenturnthe
Angle knob.
Youcanadjusttheanglein2°increments
from‐74°
to+74°.
To display the spectral trace
1 DisplaytheD‐line.
2 Doeitherofthefollowing:
•PressDopplerontheleft.
•PressModeand selectDoppler
Thetimescaleabovethetracehassmallmarks
at200msintervalsandlargemarksat
one‐secondintervals.
3 Doanyofthefollowingasneeded:
•Adjustcontrols.See“Spectraltrace
controls”
onpage 23.
•PressUpdate Doppler andUpdate 2Dto
togglebetweentheD‐lineandspectral
trace.
•Ifusingaduplexlayout,pressModeand
selectDopplertotogglebetweenthe
full‐screenD‐lineandtheduplexlayout.
Tosetaduplexlayout,see“Presetssetup”
onpage 16.
PW Doppler controls
CW, PW (Cardiac exam only) Toggles
between PW Doppler and CW
Doppler.
The current selection appears in the
mode data area.
Gate Press the button or turn the knob to
select the gate size. Settings
depend on transducer and exam
type.
Angle
Corrects the angle.
Press to correct the angle to 0°,
+60°, or -60°.
For a finer adjustment (2°
increments from -74° to +74°), press
the Angle key and then turn the
Angle knob. The current setting
appears in the mode data area. You
can correct the angle whether the
image is frozen or live.
Available in PW Doppler.
PW/TDI (Cardiac exam only) Turns tissue
Doppler imaging on and off. When
on, TDI appears in the mode data
area.
Available in PW Doppler.
