52 Patient report
iFromthecalculationsmenu,selectthe
measurementnameunderVolume.(If
VolumeisnotavailableinaGynexam,
selectGynandthenselectVolume.)
ii Positionthecalipers.(See“Working
withcalipers”onpage 33.)
iii Savethemeasurement.(See“Tosavea
calculation”onpage 38.)
Patient report
Thepatientreportcontainscalculationresults
andpatientinformationfortheexam.ForOBand
Cardiacexams,thepatientreporthasadditional
detailsandfeatures.
TheS‐FASTsystemhasEMEDworksheets
insteadofapatientreport.See“EMED
worksheets(S‐FAST)”onpage 53.
Thevalueforacalculat ion appearsonlyif
the
calculationisperformed.Thenumbersign(#)
indicatesavaluethatisoutofrange(forexample,
toolargeorsmall).Calculationvaluesthatareout
ofrangearenotincludedinderivedcalculations
(forexample,mean).
Youcandisplaythepatientreportatanytime
duringtheexam.
Foradefinitionoftermsin
patientreports,see“Glossary”onpage 141.
To display the patient report
1 Afterorduringtheexam,dooneofthe
following:
•PressOptions,andthenselectReport.
•PressPatient,andthenpressReport.
2 Todisplayadditionalpages,press x/x.
Toexitthe patientreportandreturntoimaging,
pressDone.
OB patient report
To delete an OB measurement
1 DisplaytheOBpatientreport.
2 Selectthemeasurementstodelete:
•Selectonemeasurementbyclickingit.
•Selectallmeasurementsbyclickingthe
measurementname.
Theselectedmeasurementsarehighlighted
green.
3 PressDelete.
Cardiac patient report
To delete a cardiac measurement
1 OntheDetailspageofthepatientreport,
selectthemeasurementbyusingthe
touchpad.(Theselectedmeasurementis
green.)
2 SelectDeleteon‐screen.
Deletingsomemeasurementsalsodeletes
relatedmeasurements.Deleted
measurementsarenotincludedinthe
summaryinformation.
To adjust the RA pressure
 OntheSummarypageofthecardiacpatient
report,selectfromtheRAlist.
ChangingtheRApressurefromthedefault5
affectstheRVSPcalculationresult.
