Manual Integrator Supercal 531 06-06-2011 34
C
umul
ated Volume
Possible volume units: m
3
, US-gallon
Default parameterisation ex works: m
3
Maximal displayed volume: 99'999’999
The number of digits after the decimal point can be set at the
factory or by an authorized laboratory.
The displays of the cumulated volumes for tariff 1 and tariff 2
are identical.
Cumulated values for the additional pulse inputs
A 1 and A 2
Display in main menu: without units
Units and pulse factors are defined in the menu configuration.
In case of M-Bus- or radio readout, the units are transmitted
automatically.
Temperatur
e
h
ig
h
a
nd
t
emperatur
e
low
Possible temperature units: °C or F
Default parameterisation ex works: °C
Display range: - 20 up to 200 °C
„Temperature high“ and „temperature low“ are displayed side
by side with one digit after the decimal point.
Negative temperatures are displayed with a minus sign.
Temperature difference
Display: with two digits after the decimal point
If „temperature low“ is above „temperature high“, the
temperature difference is displayed with a minus sign.
Power
Possible units of energy: kW, MW, or BTU/h
Default parameterisation ex works: kW
The number of digits after the decimal point can be set at the
factory or by an authorized laboratory.
Flow
Possible flow units: m
3
/h, US-gallon/min
Default parameterisation ex works: m
3
/h
The number of digits after the decimal point can be set at the
factory or by an authorized laboratory.
Segment test
All segments of the LCD-display appear.
