Manual Integrator Supercal 531 06-06-2011 39
7.5 Menu average values
With the Supercal 531 a maximum of 32 average values can be readout and recorded. The aver-
age time can be set between 1 minute and 45 days.
The average values for the current power, flow, „temperature high“ and „temperature low“, tem-
perature difference, flow A1 and flow A2 are recorded and displayed with the index „avg“.
The index „01 avg“ stands for the last recorded average value, index „02 avg“ stands for the aver-
age value before the last, the indices „03 avg“ to „32 avg“ stand for the previous average values.
Display and presentation of the average values are identical with those of the main menu.
Path:
Please proceed as described in 7.1.
Then press the control key three times:
The index for the menu navigation goes to „4“. Confirm the
menu 4 = menu average values by pressing the enter key:
The index for the menu navigation which is above „4“ flashes
and the current power of the last recorded average value with
the index „01 avg“ is displayed.
all further recorded
data of average value 01 can be called:
flow, supply and return temperature, temperature difference,
flow A1 and flow A2.
Menu average values
Menu monthly values
Main menu
etc.
Average
value 01
