Manual Integrator Supercal 531 06-06-2011 41
7.6 Menu maximum values
The time window for 32 maximum values can be selected freely between 1 hour and 1 year. The
maximum values for performance, flow, „temperature high“ and „temperature low“, temperature
difference and pulse inputs A1 and A2 are supplemented by the index „max“. Date and time of the
recorded maximum values are also displayed.
Index „01 max“ refers to the last maximum value , index „02 max“ refers to the value before last
month, the indices „03 max“ to „32 max“ refer to the previous maximum values.
The maximum values can be determined in two different ways:
The effective maximum values are measured and recorded during a defined average time.
The maximum values of the average values measured and recorded within the programmed aver-
age time are used.
Path:
Please proceed as described in 7.1.
Press the control key four times:
The index for the menu navigation goes to „5“. Confirm the
menu 5 = menu maximum values by pressing the enter key:
The index for the menu navigation which is above „5“ flashes
and the current performance of the last recorded maximum
value with the index „01 max“ is displayed.
