Manual Integrator Supercal 531 06-06-2011 43
7.7 Menu configuration
Here, the configuration values of the Supercal 531 can be checked and altered if required.
Path:
Please proceed as described in 7.1.
Press the control key five times:
The index for the menu navigation goes to „6“. Confirm the
menu 6 = menu configuration by pressing the enter key:
The index for the menu navigation which is above „6“ flashes
and the current date (index DA) is displayed.
By repeatedly pressing the control key the display sequence
of the menu configuration can be called:
Time (index Hr)
No differentiation is made between summer and winter period.
Pulse factor flow sensor (index „LP“ or PL) litre/pulse or
pulse/litre
Menu configuration
Menu maximum values
Main menu
Max. value 01
current power
etc.
Pulse factor
Flow sensor
Pulse units for
A1 and A2
Pulse factor for
A1 and A2
Ttime
Date
