Manual Integrator Supercal 531 06-06-2011 74
The interfaces of the NOWA-adapter
Prüfstand
NOWA
Wärme-
zähler
Wärme-
zähler
q
∆ϑ
∆ϑ∆ϑ
∆ϑ ∆ϑ
∆ϑ∆ϑ
∆ϑ
S 1
S 2
∆ϑ
∆ϑ ∆ϑ
∆ϑ
- Simulation
(optional)
S 3
(optional)
Over the interface S1 the test rig communicates the NOWA-function on the basis of defined speci-
fications.
Over the interface (s) S2 NOWA controls the integrators acc. to the function set via S1.
Over the interface S3 NOWA controls an optional set-up to simulate the temperature sensors.
The NOWA-system can be used with manual and semi-automatic test rigs as well as with auto-
mated test rigs.
Due to the flexible concept of interface S2 up to 15 integrators can be submitted to the official cali-
bration test at the same time. With the so-called multiplexing, it is possible to submit more than 15
process systems to the test and to guarantee further added functions (e.g. higher data transfer
rates, parallel transmission etc.).
Further advantages of the NOWA-concept:
High security with regard to errors in the handling of the test procedures
Lower production and quality assurance costs for the integrator manufacturers
Improved consumer protection
The NOWA.EXE file allows the adaptation to various applications and firmware configuration of
modern integrators.
