301 INPUT CONFIGURATION menu (1/2): Set input signal data for each channel.
xxCH: Current channel is indicated. Enter a channel number with the numeric keypad if changing the
channel. The settings below will be stored as information about the signal to be connected to this
channel.
FORMAT...: Select the input signal type. ÷ 310
SLOT NO: Enter the slot number.
INPUT NO: Enter the input connector number.
YC SEP...: Select a Y/C separation filter. ÷ 315
SYNC MODE: Select the sync signal.
INT: Use an internal sync signal.
EXT: Use an external sync signal.
SCREEN MODE...: Select the scan size. ÷ 320
SAFE AREA: Choose whether or not to display the safe area (OFF or ON).
SAFE AREA SCALE...: Select the safe area size. ÷ 322
APERTURE: Choose whether or not to use aperture adjustment (OFF or ON).
APERTURE VALUE: Enter the aperture adjustment value (0 to 200).
301 INPUT CONFIGURATION menu (2/2): Set input signal data for each channel.
xxCH: Current channel is indicated. Enter a channel number with the numeric keypad if changing the
channel. The settings below will be stored as information about the signal to be connected to this
channel.
FILTER: Switch the filter operation (OFF or ON) when the monochrome display is selected.
CHANNEL NAME...: Give the channel a name. ÷ 326
CONTROL: Select whether to use local (“CH SET”) or common (“PRESET”) values for contrast,
brightness, chroma, and phase.
PRESET: Use common data.
CH SET: Use values set for each channel.
COLOR TEMP...: Set the color temperature. ÷ 328
H PHASE: Set the horizontal picture position (–127 to +128).
1)
SAD H POSITION: Adjust the horizontal display position of the safety area (–127 to +128).
1)
COPY...: Select a method for copying data from elsewhere. ÷ 330
1) The monitor will not operate correctly if values above or below the allowable range are entered.
310 FORMAT (xxCH): Select the signal format.
Note
If there is no input connector or decoder corresponding to a format, that format will not be
selectable (the cursor will skip over that item).
COMPOSITE...: Composite signal. ÷ 311
YC...: Y/C signal. ÷ 311
COMPONENT...: Component or RGB signal. ÷ 312
SDI...: Serial digital signal. ÷ 313
Setting the Input Configuration — INPUT CONFIGURATION Menu
