Sony CDP-M400CS - Front Panel Assembly; JOG Board, DISP Board, KEYBOARD Board

10
CDP-M400CS
3-6. FRONT PANEL ASSEMBLY
3-7. JOG BOARD, DISP BOARD, KEYBOARD BOARD
2
3
connector (CNP503)
5 two screws
(BVTP 3
× 8)
4 screw
(BVTP 3
× 8)
6 three screws
(BVTP 3
× 8)
7 remove the claw
8 remove the cla
w
9 front panel assembly
1
qs Remove two solderings.
1 knob (AMS)
2 knob (disc)
3 four screws
(BVTP 2.6
× 8)
4 bracket (case)
assembly
5 eleven screws
(BVTP 2.6
× 8
)
7 eight screws
(BVTP 2.6
× 8)
qa two screws
(BVTP 2.6
× 8)
8 DISP board
9 flat type wire
(17 core)
0 knob
(timer)
6 JOG board
qf KEYBOARD
board
qd bracket (keyboard)
