Sony CDP-M400CS - Back Panel Section; D.SENS (OUT) Board, D.SENS (IN) Board

15
CDP-M400CS
3-15. D.SENS (OUT) BOARD, D.SENS (IN) BOARD
3-16. BACK PANEL SECTION
5 screw
(PSW 3
× 8)
6 D.SENS (OUT) board
1 screw
(PTTWH 3
× 6)
2 clamp
8 D.SENS (IN) board
3 two step screws (T1)
4 bracket (sensor 400
)
7 screw
(PTTWH 3
× 6)
1 nine screws (BVTP 3 × 8
)
2 cover (CDM)
3 three screws
(BVTP 3
× 8)
4 bracket (CDM)
5
6
connector (CN991)
7 four screws
(BVTP 3
× 8)
8 back panel section
flat cable clamp
