Sony CDP-M400CS - Chassis Section 2

53
CDP-M400CS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 3-703-249-02 SCREW, S TIGHT, +PTTWH 3X6
102 4-225-873-01 HOLDER (TABLE SENSOR 400)
103 4-216-096-02 SCREW (T1), STEP
104 3-701-447-21 WASHER, 10
105 4-216-089-02 SHAFT (CENTER)
* 106 3-378-400-01 CUSHION, SARANET
107 4-216-093-01 ROLLER
108 4-216-092-03 HOLDER (ROLLER)
109 4-965-822-01 FOOT
110 X-2022-049-1 FOOT ASSY
111 4-216-088-02 GUIDE (DISC)
112 1-676-828-11 T.SENS BOARD
113 1-683-724-13 D.SENS (OUT) BOARD
114 1-683-723-13 D.SENS (IN) BOARD
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#4 7-685-903-11 SCREW +PTPWH 3X6 (TYPE2)
#5 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
#7 7-682-948-01 SCREW +PSW 3X8
not supplied
#1
#5
#5
#5
#1
#1
#1
#7
#1
#1
109
110
106
108
107
not supplied
104
105
102
112
101
113
103
114
#7
not supplied
101
101
#7
not supplied
106
#4
111
MECHANISM SECTION 2
(CDM62-K1BD46A)
7-3. CHASSIS SECTION 2
