CDP-M400CSNW-E53
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
•Abbreviation
CND : Canadian model
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4727-735-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-126-208-21 ELECT CHIP 47uF 20% 4V
C113 1-128-995-21 ELECT CHIP 100uF 20% 10V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-128-995-21 ELECT CHIP 100uF 20% 10V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C120 1-126-208-21 ELECT CHIP 47uF 20% 4V
C121 1-117-920-11 TANTAL. CHIP 10uF 20% 6.3V
C131 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C132 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C133 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C150 1-128-995-21 ELECT CHIP 100uF 20% 10V
C151 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C152 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C158 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C201 1-126-246-11 ELECT CHIP 220uF 20% 4V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C206 1-126-208-21 ELECT CHIP 47uF 20% 4V
C207 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C216 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C223 1-126-208-21 ELECT CHIP 47uF 20% 4V
C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C226 1-126-208-21 ELECT CHIP 47uF 20% 4V
C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C229 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C230 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C231 1-128-995-21 ELECT CHIP 100uF 20% 10V
C232 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C250 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C251 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C252 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C253 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C254 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C255 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C256 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C257 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C258 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C259 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C260 1-126-246-11 ELECT CHIP 220uF 20% 4V
C261 1-126-208-21 ELECT CHIP 47uF 20% 4V
C263 1-117-920-11 TANTAL. CHIP 10uF 20% 6.3V
C264 1-126-208-21 ELECT CHIP 47uF 20% 4V
C265 1-126-208-21 ELECT CHIP 47uF 20% 4V
C266 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C267 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C268 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C269 1-117-920-11 TANTAL. CHIP 10uF 20% 6.3V
C270 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C271 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C276 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C292 1-115-156-11 CERAMIC CHIP 1uF 10V
C297 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN101 1-784-879-21 CONNECTOR, FFC (LIF (NON-ZIF)) 31P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD/RESISTOR >
FB101 1-500-283-11 INDUCTOR, FERRITE BEAD
FB102 1-500-283-11 INDUCTOR, FERRITE BEAD
FB103 1-500-283-11 INDUCTOR, FERRITE BEAD
FB104 1-500-283-11 INDUCTOR, FERRITE BEAD
FB105 1-216-864-11 SHORT CHIP 0
BD
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
When indicating parts by reference number,
please include the board name.
