61
CDP-M400CS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FB111 1-216-864-11 SHORT CHIP 0
FB251 1-414-594-11 INDUCTOR, FERRITE BEAD
FB291 1-216-864-11 SHORT CHIP 0
FB292 1-216-864-11 SHORT CHIP 0
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC103 8-752-089-74 IC CXA2581N-T4
IC104 6-701-810-01 IC TC94A20F-CX4
IC105 6-700-226-01 IC TC74LVX04FT (EL)
IC121 6-701-808-01 IC BA33C25FP-E2
IC150 8-759-677-90 IC BA5947FP-E2
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR >
R101 1-216-864-11 SHORT CHIP 0
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-846-11 METAL CHIP 120K 5% 1/10W
R113 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R114 1-218-745-11 METAL CHIP 160K 0.5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/10W
R120 1-216-846-11 METAL CHIP 120K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-797-11 METAL CHIP 10 5% 1/10W
R124 1-216-797-11 METAL CHIP 10 5% 1/10W
R125 1-216-834-11 METAL CHIP 12K 5% 1/10W
R126 1-216-834-11 METAL CHIP 12K 5% 1/10W
R131 1-216-845-11 METAL CHIP 100K 5% 1/10W
R132 1-216-853-11 METAL CHIP 470K 5% 1/10W
R133 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R151 1-216-845-11 METAL CHIP 100K 5% 1/10W
R152 1-216-849-11 METAL CHIP 220K 5% 1/10W
R153 1-216-864-11 SHORT CHIP 0
R155 1-216-864-11 SHORT CHIP 0
R156 1-216-864-11 SHORT CHIP 0
R201 1-216-839-11 METAL CHIP 33K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R207 1-216-857-11 METAL CHIP 1M 5% 1/10W
R213 1-216-864-11 SHORT CHIP 0
R214 1-216-864-11 SHORT CHIP 0
R215 1-216-864-11 SHORT CHIP 0
R216 1-216-857-11 METAL CHIP 1M 5% 1/10W
R218 1-216-821-11 METAL CHIP 1K 5% 1/10W
R219 1-216-821-11 METAL CHIP 1K 5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R230 1-216-813-11 METAL CHIP 220 5% 1/10W
R231 1-216-817-11 METAL CHIP 470 5% 1/10W
R232 1-216-817-11 METAL CHIP 470 5% 1/10W
R233 1-216-817-11 METAL CHIP 470 5% 1/10W
R249 1-216-817-11 METAL CHIP 470 5% 1/10W
R250 1-216-813-11 METAL CHIP 220 5% 1/10W
R251 1-216-813-11 METAL CHIP 220 5% 1/10W
R252 1-216-857-11 METAL CHIP 1M 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-845-11 METAL CHIP 100K 5% 1/10W
R265 1-216-813-11 METAL CHIP 220 5% 1/10W
R266 1-216-813-11 METAL CHIP 220 5% 1/10W
R271 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT IN)
< VIBRATOR >
X201 1-795-154-21 VIBRETOR, CRYSTAL (16.9MHz)
*************************************************************
1-683-729-13 D.MOTOR BOARD
**************
< MOTOR >
M603 1-541-632-12 MOTOR, DC (DOOR)
*************************************************************
1-683-723-13 D.SENS (IN) BOARD
****************
* 4-985-300-02 HOLDER (P-T)
< TRANSISTOR >
Q81 8-729-921-53 PHOTO TRANSISTOR PT483F1
*************************************************************
1-683-724-13 D.SENS (OUT) BOARD
******************
* 4-976-473-01 HOLDER (LED-S)
< DIODE >
D81 8-719-055-84 DIODE GL528VS1
*************************************************************
A-4727-719-A DISP BOARD, COMPLETE
*********************
4-982-811-21 HOLDER (FL)
< CAPACITOR >
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C781 1-104-658-91 ELECT 100uF 20% 10V
C782 1-104-658-91 ELECT 100uF 20% 10V
C784 1-162-282-31 CERAMIC 100PF 10% 50V
C785 1-162-282-31 CERAMIC 100PF 10% 50V
C786 1-162-282-31 CERAMIC 100PF 10% 50V
C787 1-162-306-11 CERAMIC 0.01uF 20% 16V
C788 1-162-215-31 CERAMIC 47PF 5% 50V
C789 1-164-159-11 CERAMIC 0.1uF 50V
BD D.MOTOR D.SENS (IN) D.SENS (OUT) DISP
