67
CDP-M400CS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C942 1-109-953-11 ELECT 2.2uF 20% 50V
C943 1-164-159-11 CERAMIC 0.1uF 50V
C951 1-136-173-00 MYLAR 0.47uF 5% 50V
C961 1-136-165-00 MYLAR 0.1uF 5% 50V
C962 1-164-159-11 CERAMIC 0.1uF 50V
C963 1-164-159-11 CERAMIC 0.1uF 50V
C971 1-136-165-00 MYLAR 0.1uF 5% 50V
C972 1-164-159-11 CERAMIC 0.1uF 50V
C973 1-164-159-11 CERAMIC 0.1uF 50V
0C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
C992 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C993 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN601 1-506-469-11 PIN, CONNECTOR 4P
CN602 1-506-469-11 PIN, CONNECTOR 4P
CN603 1-568-951-11 PIN, CONNECTOR 2P
* CN991 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CNP902 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D901 8-719-210-21 DIODE 11EQS04
D902 8-719-210-21 DIODE 11EQS04
D903 8-719-210-21 DIODE 11EQS04
D904 8-719-210-21 DIODE 11EQS04
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-719-150-92 DIODE RD33EB3T
D913 8-719-109-93 DIODE RD6.2ESB2
D921 6-500-522-11 DIODE 10EDB40-TA2B5
D922 6-500-522-11 DIODE 10EDB40-TA2B5
D923 6-500-522-11 DIODE 10EDB40-TA2B5
D924 6-500-522-11 DIODE 10EDB40-TA2B5
D931 6-500-522-11 DIODE 10EDB40-TA2B5
D932 6-500-522-11 DIODE 10EDB40-TA2B5
D933 6-500-522-11 DIODE 10EDB40-TA2B5
D934 6-500-522-11 DIODE 10EDB40-TA2B5
D935 8-719-110-41 DIODE RD15ESB2
D991 8-719-991-33 DIODE 1SS133T-77
< IC >
IC941 8-759-822-38 IC LA6510
IC961 8-759-822-38 IC LA6510
< LINE FILTER >
0L991 1-424-485-11 FILTER, LINE
< TRANSISTOR >
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q911 8-729-140-97 TRANSISTOR 2SB734-34
Q931 8-729-620-05 TRANSISTOR 2SC2603-EF
Q941 8-729-900-65 TRANSISTOR DTA144ES
Q942 8-729-900-89 TRANSISTOR DTC144ES
Q951 8-729-900-65 TRANSISTOR DTA144ES
Q952 8-729-900-89 TRANSISTOR DTC144ES
< RESISTOR >
R901 1-247-831-91 CARBON 1K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-421-11 CARBON 2.2K 5% 1/4W
R904 1-249-429-11 CARBON 10K 5% 1/4W
R911 1-247-847-91 CARBON 4.7K 5% 1/4W
R912 1-249-421-11 CARBON 2.2K 5% 1/4W
R913 1-247-847-91 CARBON 4.7K 5% 1/4W
R914 1-247-807-31 CARBON 100 5% 1/4W
R931 1-249-421-11 CARBON 2.2K 5% 1/4W
R932 1-249-421-11 CARBON 2.2K 5% 1/4W
R940 1-247-807-31 CARBON 100 5% 1/4W
R941 1-247-807-31 CARBON 100 5% 1/4W
R942 1-249-421-11 CARBON 2.2K 5% 1/4W
R943 1-247-879-91 CARBON 100K 5% 1/4W
R944 1-247-831-91 CARBON 1K 5% 1/4W
R945 1-247-879-91 CARBON 100K 5% 1/4W
R946 1-247-883-00 CARBON 150K 5% 1/4W
R947 1-247-847-91 CARBON 4.7K 5% 1/4W
R948 1-249-381-11 CARBON 1 5% 1/4W
R949 1-249-381-11 CARBON 1 5% 1/4W
R951 1-247-807-31 CARBON 100 5% 1/4W
R952 1-249-421-11 CARBON 2.2K 5% 1/4W
R953 1-247-879-91 CARBON 100K 5% 1/4W
R954 1-247-831-91 CARBON 1K 5% 1/4W
R955 1-247-879-91 CARBON 100K 5% 1/4W
R956 1-247-883-00 CARBON 150K 5% 1/4W
R957 1-247-847-91 CARBON 4.7K 5% 1/4W
R958 1-249-381-11 CARBON 1 5% 1/4W
R959 1-249-381-11 CARBON 1 5% 1/4W
R961 1-247-883-00 CARBON 150K 5% 1/4W
R962 1-247-860-11 CARBON 16K 5% 1/4W
R963 1-247-883-00 CARBON 150K 5% 1/4W
R964 1-247-883-00 CARBON 150K 5% 1/4W
R965 1-249-431-11 CARBON 15K 5% 1/4W
R966 1-249-381-11 CARBON 1 5% 1/4W
R967 1-249-381-11 CARBON 1 5% 1/4W
R968 1-249-393-11 CARBON 10 5% 1/4W
R971 1-247-883-00 CARBON 150K 5% 1/4W
R972 1-247-860-11 CARBON 16K 5% 1/4W
R973 1-247-885-00 CARBON 180K 5% 1/4W
R974 1-247-885-00 CARBON 180K 5% 1/4W
R975 1-249-431-11 CARBON 15K 5% 1/4W
R976 1-249-381-11 CARBON 1 5% 1/4W
R977 1-249-381-11 CARBON 1 5% 1/4W
R978 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
0RY991 1-755-299-11 RELAY
< TRANSFORMER >
0T901 1-437-709-11 TRANSFORMER, POWER
0T911 1-435-327-11 TRANSFORMER, POWER
*************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
TRANS
