Overview 1-23
Chapter 1 Overview
Power supplied through this connector
is used on a priority basic even when
you have connected a battery pack or
AC-DN2(A) AC Adaptor to the
battery connector on the top panel.
For more information, see section 2-1
“Power Preparations”.
4 TC OUT (timecode output)
connector (BNC type)
Outputs the following types of
timecode, depending on the VTR
operating status.
During playback: The playback
timecode
During recording: The timecode
generated by the internal
timecode generator, or the
timecode input through the TC
IN connector.
5 AUX connector
This connector is used only for
service.
6 DC OUT connector
This connector supplies power to the
BVR-3 Remote Control Unit.
7 SDI OUT (serial digital interface
output) connectors (BNC type)
Output a D-1 format video/audio
signal. The same signals are output
from the left and right connectors.
8 SDI IN (serial digital interface
input) connector (BNC type)
Input a D-1 format video/audio signal.
When editing with two DNW-A25/
A25P units, connect the SDI OUT
connector 7 on the player unit with
this connector on the recorder unit.
