Camera Adaptor
CA-537/537P (Optional)
For details, refer to the CA-537/537P operating
instructions.
Inputs/Outputs VTR/CCU/CMA connector:
Sony Z-type, 26-pin
DC IN: XLR-type, 4-pin, male
MIC IN: XLR-type, 3-pin, female
GEN LOCK IN: BNC-type,
75-ohms, unbalanced
EARPHONE: mini jack
INTERCOM: mini intercom
Power requirements 12 V DC
Power consumption 1.7 W
Operating temperature
–10°C to +45°C (14°F to 113°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Weight About 1.3 kg (2 lb 14 oz)
Dimensions 118 × 205 × 118 mm (w/h/d)
(4
3
/4 × 8
1
/8 × 4
3
/4 inches)
Zoom Lens VCL-714BX
Focal length 7.5 mm to 105 mm
Zoom Manual and motorized, selectable
Zooming ratio: 14×
Maximum aperture ratio
1:1.4 (7.5 to 75 mm) to 1:1.8 (105
mm)
Iris control Manual and auto, selectable
1.4 to 16 and C (closed)
Range of object field (at the distance of 1.1 meter)
W (wide angle) 660 × 880 mm
(26 × 34
3
/4 inches)
T (telephoto) 47 × 63 mm (2
1
/4 × 3 inches)
Minimum object distance
1.1 m (3
3
/4 inches)
Filter thread 72 mm dia., 0.75 mm-pitch
Mount Bayonet mount,
1
/2 inch
Weight About 1.1 kg (2 lb 10 oz)
with hood
Dimensions About 110 mm dia. × 186 mm
(Focus: ∞ )
(4
3
/8 × 7
1
/2 inches)
Viewfinder DXF-601/601CE
Picture tube 1.5-inch monochrome
Indicators REC/TALLY indicator
BATT indicator
SHUTTER indicator
GAIN UP indicator
Resolution 600 lines
Power requirements 12 V DC
Power consumption 2.1 W
Weight About 640 g (1 lb 2 oz)
not including a microphone holder
Dimensions About 206 × 79 × 219 mm (w/h/d)
(7
1
/4 × 2
3
/4 × 8
1
/8 inches)
Carrying Case LC-421
Weight About 7.7 kg (17 lb)
Dimensions About 790 × 440 × 340 mm
(w/h/d)
(31
1
/8 × 17
3
/8 × 13
1
/2 inches)
Accessories Supplied
VCL-714BX zoom lens (supplied with
the DXC-327BK/327BPK/327BF/327BPF only) (1)
DXF-601/601CE electronic viewfinder (supplied with
the DXC-327BK/327BPK/327BL/327BPL/327BF/
327BPF only) (1)
LC-421 carrying case (supplied with the DXC-327BF/
327BPF only) (1)
VCT-U14 tripod attachment (supplied with the
DXC-327BK/327BPK/327BL/327BPL/327BF/
327BPF only) (1)
Lens cap (1)
Chart for flange focal length adjustment (1)
Design and specifications are subject to change
without notice.
